QUADRI Simone cycles

Foxy

frame Foxy Stelth alloy Zero Suspension System 140mm
sizes S / M / L / XL
rear shock Fox Float RL 200x57mm
fork Fox 32 Float RL 140mm
stem Onoff Notion SB 60mm
handlebar Mondraker Foxy custom design 31.8mm 710
brake Avid Elixir 1 180mm
rims Onoff Rail wheelset
spokes CN stainless
tires WTB Volverine 2.2 Comp
crankset Sram S-1000 39x26T
bottom bracket Sram GXP
pedals Mtb Spd
chain Sram PC-1031 10s
front derailleur Shimano SLX FD M-661-10D Direct mount
Sram X7 /shifters Sram Trigger X-5
cassette Sram PG-1030 11-36T 10s
weight w/o pedals 13.4 kg

Foxy R
frame Foxy Stelth alloy Zero Suspension System 140mm
sizes S / M / L / XL
rear shock Fox Float RP2 XV Boost Valve 200x57mm
fork Fox 32 Float FIT RL 140mm Tapered
headset Onoff Integrated Tapered 1-1/8"->1/5"
handlebar Mondraker Foxy R custom design 31.8mm 710mm
seatpost Crank Brothers Cobalt 1
brake Formula RX 180mm
rims Dt X1900 wheelset
front hub Dt X1900 QR
rear hub Dt X1900
tires WTB Volverine 2.2 Comp
crankset Sram S-1000 39x26T
bottom bracket Sram GXP
pedals /
front derailleur Shimano XT FD M-786-10D Direct mount
Sram X9 /Sram Trigger X-7
weight w/o pedals 12.8 kg

Foxy RR

frame Foxy Stelth alloy Zero Suspension System 140mm
sizes S / M / L / XL
rear shock Fox Float RP23 XV Boost Valve Kashima 200x57mm
fork Fox 32 Float RLC FIT Kashima Qr15mm 140mm Tapered
headset FSA Nº57 E 1-1/8"->1/5"
stem M-Decline AM 31.8mm 70mm
handlebar Mondraker Foxy RR custom design 31.8mm 710mm
seatpost Rock Shox Reverb remote 31.6mm
saddle Fizik Gobi XM
brake Formula RX 180mm
rims Cranck Brothers Coblalt 2 wheelset
tires Kenda Nevegal 2.10 DTC Tubuless
crankset Sram S2210 Carbon 39x26T
pedals /
front derailleur Shimano XT FD M-786-10D Direct mount
rear derailleur Sram X0 Medium cage 10s
shifters Sram Trigger X-9
cassette Sram PG-1070 12-36T 10s
weight w/o pedals 12.3 kg

Dune

frame Dune Stealth alloy Zero Suspension System 160mm
sizes M / L / XL
rear shock X-Fusion E1 R 215x63.5mm
fork Rock Shox Lyric R Coil 160mm
headset Onoff Integrated Tapered Reduced 1-1/8"
stem Onoff Notion SB 60mm
handlebar Mondraker Dune R custom design 31.8mm 710mm
seatpost Onoff Notion 0-R SB 31.6mm
brake Avid Elixir 1 180mm
rims Onoff Rail wheelset
tires WTB Bromsom 2.30 Comp
crankset Sram S600 44/32/22T
pedals /
front derailleur Shimano SLX FD M-661-10D Direct mount
rear derailleur Sram X5 Medium cage 9s
shifters Sram Trigger X-5
cassette Sram PG-950 11-32T 9s
weight w/o pedals 14.3 kg

Dune R

frame Dune Stealth alloy Zero Suspension System 160mm
sizes M / L / XL
rear shock Fox Float R XV 215x63.5mm
fork Fox 36 Float R 160mm
headset Onoff Integrated Tapered Reduced 1-1/8"
stem Onoff Notion SB 60mm
handlebar Mondraker Dune R custom design 31.8mm 710mm
seatpost Onoff Notion 0-R SB 31.6mm 350
brake Avid Elixir 1 180mm
rims Onoff Draw wheelset
tires WTB Bromsom 2.30 Comp
crankset Sram S1000 39x26T
pedals /
front derailleur Shimano SLX FD M-661-10D Direct mount
rear derailleur Sram X7 Medium cage 10s
shifters Sram Trigger X-5
cassette Sram PG-1030 12-36T 10s
weight w/o pedals 13.7 kg

Dune RR

frame Dune Stealth alloy Zero Suspension System 160mm
sizes M / L / XL
rear shock Fox Float RP2 XV Boost Valve 215x63.5mm
fork Fox 36 Float R 160mm Tapered
headset Onoff Integrated Tapered 1-1/8"->1/5"
stem M-Decline AM 31.8mm 60mm
handlebar Mondraker Dune RR custom design 31.8mm 710mm
seatpost X-Fusion Hilo Lever 31.6mm
saddle Mondraker Dune RR custom design
brake Formula RX 180mm
rims Easton Vice wheelset
tires WTB Bromsom 2.30 Comp
crankset Sram S1400 39x26T
pedals /
front derailleur Shimano XT FD M-786-10D Direct mount
rear derailleur Sram X9 Medium cage 10s
shifters Sram Trigger X-7
cassette Sram PG-1030 11-36T 10s
weight w/o pedals 13.4 kg

Dune RR Limited

frame Dune Stealth alloy Zero Suspension System 160mm
sizes M / L / XL
rear shock Fox Float RP23 XV Boost Valve Kashima 215x63.5mm
fork Fox 36 Float RLC FIT Kashima 160mm Tapered
headset FSA Nº57 E 1-1/8"->1/5"
stem M-Decline AM 31.8mm 60mm
handlebar Mondraker Dune RR LTD custom design 31.8mm 710mm
seatpost Rock Shox Reverb remote 31.6mm
saddle Fizik Gobi XM
brake Formula RX 180mm
rims Easton Haven wheelset
tires Kenda Nevegal 2.35 stick-e tubeless
crankset Sram S2210 Carbon 39x26T
pedals /
front derailleur Shimano XT FD M-786-10D Direct mount
rear derailleur Sram X0 Medium cage 10s
shifters Sram Trigger X-9
cassette Sram PG-1050 12-36T 10s
weight w/o pedals 13.2 kg

Zenith X

frame Zenith Stealth alloy Zero Suspension System 170mm
sizes M / L / XL
rear shock Fox DHX Air 5.0 215X63.5
fork Rock Shox Lyric R SA 170mm
headset FSA IS-2 1-1/8"
stem M-Decline AM 31.8mm 70mm
handlebar Mondraker Zenith X custom design 31.8mm 740mm
seatpost X-Fusion Hilo Lever 31.6mm
brake Avid Elixir 3 200/180mm
rims Onoff Eject wheelset
tires WTB Weirwolf 2.30 Comp
crankset Sram S-1000 39x26T
pedals /
front derailleur Shimano SLX FD M-661-10D Direct mount
rear derailleur Sram X9 Medium cage 10s
shifters Sram Trigger X-5
cassette Sram PG-1050 12-36T 10s
weight w/o pedals 14.7 kg

Zenith XR

frame Zenith Stealth alloy Zero Suspension System 170mm
sizes M / L / XL
rear shock Fox DHX Air 5.0 Kashima 215X63.5
fork Fox 36 Float RC2 FIT Kashima 170mm
headset FSA IS-2 1-1/8"
stem M-Decline AM 31.8mm 70mm
handlebar Mondraker Zenith XR custom design 31.8mm 740mm
seatpost Rock Shox Reverb remote 31.6mm
brake Formula RX 203mm/180mm
rims Onoff Eject wheelset
tires WTB Weirwolf 2.30 Comp
crankset Sram X9 39x26T
pedals /
front derailleur Shimano XT FD M-786-10D Direct mount
rear derailleur Sram X0 Medium cage 10s
shifters Sram Trigger X-9
cassette Sram PG-1050 12-36T 10s
weight w/o pedals 14.4 kg

Prayer

frame Prayer 6061 Hydroformed Tech FR 180mm
sizes S / M / L
rear shock Fox Van R 222x70mm
fork Marzocchi 66 RCV 180mm
headset FSA ZS-4D 1-1/8" Integrated
stem Onoff Morph Slope 31.8mm 50mm
handlebar Onoff Morph FR 31.8mm 740mm
seatpost Onoff Notion 1-R 31.6mm 350mm
front brake Avid Elixir 1 200mm/ 180mm
rims Onoff Bula wheelset
tires WTB Dissent Comp 2.3
crankset Truvativ Ruktion 1.0 36T
pedals Onoff Claw
front derailleur Chainguide E.13 LS1
rear derailleur Sram X7 Medium cage 9s
shifters Sram Trigger X-5
cassette Sram PG-950 11-32T 9s
weight w/o pedals 17.0 kg

kaiser

frame Kaiser Monocoque Signature 6061 T6 215mm
sizes 16" one size
rear shock Fox Van R 241x76mm
fork Marzocchi 888 RV 200mm
headset FSA Th-848 1-1/8"
stem M-Decline Integrated 50mm
handlebar Onoff Morph FR 31.8mm 740mm
seatpost Onoff Notion 1-R 31.6 350mm
brake Avid Elixir 1 200mm
rims Onoff Bula wheelset
tires WTB Dissent Comp 2.3
crankset Truvativ Ruktion 1.0 38T
bottom bracket Truvativ Howitzer XR
pedals Onoff Claw
front derailleur Chainguide E.13 LS1
rear derailleur Sram X7 Short cage 9s
shifters Sram Trigger X5
cassette Sram PG-950 11-28T 9s
weight w/o pedals 18.2 kg

Summum

frame Summum Stealth alloy Zero Suspension System 210mm
sizes S / M / L
rear shock Fox RC2 241x76mm
fork Rock Shox Boxxer RC 200mm
headset FSA IS-2 1-1/8"
stem M-Decline Integrated 50mm
handlebar Mondraker Anodized DH 31.8mm 780mm
seatpost Easton EA-30 Offset 31.6 350mm
brake Formula RX 203mm
rims Dt F630
front hub Onoff Disc Pro DH 20mm
rear hub Onoff Disc Pro DH 12x150mm
tires Kenda Nevegal 2.35 stick-e
crankset Truvativ Hussefelt 1.0 165mm 38T
bottom bracket Truvativ Howitzer XR
pedals /
front derailleur Chainguide E.13 LS1
rear derailleur Sram X9 Short cage 9s
shifters Sram Trigger X7
cassette Sram PG-950 11-26t 9s
weight w/o pedals 16.5 kg

Summum Pro Team

frame Summum Stealth alloy Zero Suspension System 210mm
sizes S / M / L
rear shock Fox RC4 Kashima 241x76mm
fork Fox 40 RC2 Fit Kashima 200mm
headset FSA IS-2 1-1/8"
stem M-Decline Integrated 50mm
handlebar Mondraker Anodized DH 31.8mm 780mm
seatpost Easton EC-70 Zero 31.6 300mm
brake Formula The One 203mm
rims Easton Havoc Wheelset
front hub Easton Havoc 20mm
rear hub Easton Havoc 12 x 150mm
tires Kenda Nevegal 2.35 stick-e
crankset Sram X0 DH 1.1 165mm 38T
pedals /
front derailleur Chainguide E.13 LG1
rear derailleur Sram X0 DH 10s
shifters Sram Trigger X0 DH
cassette Sram PG-1070 11-26t 10s
weight w/o pedals 15.6 kg
